Picasso Bundle

Responsive images

A responsive image lists several variants of the same image in a srcset, and lets the browser download the one that fits the screen. Picasso writes that list for you. The only thing it cannot guess is how wide the image is displayed in your layout: that is the sizes prop.

Two kinds of images

Section titled “Two kinds of images”

The image width depends on the viewport (full-width banner, column of a grid…). Give sizes, and the srcset lists every width of device_sizes and image_sizes, up to the source width:

<twig:Picasso:Image src="photo.jpg" width="800" height="600" sizes="(max-width: 768px) 100vw, 800px" alt="…" />
srcset="…?w=16… 16w, …?w=32… 32w, … , …?w=1920… 1920w"

What the browser picks

Section titled “What the browser picks”

sizes tells the browser how many CSS pixels the image takes, the screen density turns them into device pixels, and the browser takes the first variant at least that wide. With sizes="(max-width: 768px) 100vw, 800px":

640 px wide variant
640w
18 KB: a 320 px wide phone at 2x
1080 px wide variant
1080w
33 KB: a 360 px wide phone at 3x
1920 px wide variant
1920w
66 KB: the 800 px column at 2x needs 1600, the next width is 1920
WebP variants of the same source, rendered by Glide. Without a srcset, every screen would download the largest.

Writing sizes:

  • Describe the layout, not the image: (max-width: 768px) 100vw, 800px reads “full width on small screens, 800 CSS pixels otherwise”.
  • The first matching condition wins: list the narrow screens first.
  • An approximation is fine. Too large wastes bytes, too small blurs the image.
  • In a grid of three columns: (max-width: 768px) 100vw, 33vw.

Formats

Section titled “Formats”

Each format of formats but the last becomes a <source>, tried in order, and the last one is the <img> fallback. The default [avif, webp, jpg] serves AVIF to browsers that support it, WebP to the others, and JPEG to the rest.

Every format multiplies the variants of each image: 16 widths × 3 formats is 48 renders for a crawler fetching them all. Trimming the widths your layout never uses, or dropping WebP when you serve AVIF, cuts the cost of a cold cache.

Avoiding layout shifts

Section titled “Avoiding layout shifts”

The browser reserves the space of an image from its width and height attributes, before it loads. Picasso only writes them when it knows both:

  • give both, or
  • give one, and let Picasso read the other from the source: this needs metadata resolution, on by default for filesystem loaders.
